Close the sprocket covers.

Slide the right sprocket unit to remove any slack in the paper.

Then lock it in place by pushing the sprocket lock lever
back.

Place the notches on the paper guide straight down over the
mounting posts on the printer.

Slightly lift the paper guide and then lower it until it rests on
the printer. Raise the paper-guide cover and rest it on the

paper guide.

10. Slide both edge guides to the middle of the paper guide.

11. Turn on the printer. The printer automatically advances the

paper to the loading position when it receives data.

Note:

You can also advance the paper to the loading position by pressing the

LOAD/EJECT button.

Caution:

Use the knob on the right side of the printer only to clear paper

jams when the printer is off. Otherwise, you may damage the

printer or cause it to lose the top-of-form position.

2-14 Paper Handling
