Print position motion
ASCII Dec. Hex, Description
ESC $ nl n2 36 24 Set Absolute Horizontal Print
Position
n = n 1 + n 2 x 2 5 6
n: Specifies print position
from left margin in defined
units
The default unit is 1/60 inch.
ESC \ nl n2 92 5C Set Relative Horizontal Print
Position
n = n 1 + n 2 x 2 5 6
n: Moves current print
position in defined units
The default unit is 1/120 inch in draft mode and 1/180
inch in LQ mode.
ESC (V nn
ESC (v nn
ESC D nn
4086 2856 Set Absolute Vertical Print
Position
ESC (V 20 nl n2
n = n 1 + n 2 x 2 5 6
n: Specifies print position
from top margin in defined
units
40118 2876 Set Relative Vertical Print
Position
ESC(v 2 0 n1 n2
n = n 1 + n 2 x 2 5 6
n: Moves current print
position in defined units
68 44 Set Horizontal Tabs
Up to 32 tabs (l-255) entered
in ascending order;
Terminated by O
Command Summay 8-5
