Installing in the pull-tractor position
1.
2.
3.
4.
5.
6.
Make sure the power is turned off. Remove the paper guide.
Raise the paper-guide cover and rest it on the printer cover.
Lift the printer cover up and off.
Grasp both ends of the clear plastic paper-tension unit and
lift it up from the front and lift it off the printer.
If necessary, remove the tractor from the push-tractor
position by pressing the lock tabs open while lifting the
tractor up and out of the mounting slots.
Push the tractor’s lock tabs into the open position. Tilt the
tractor forward and lower it into the printer’s front
mounting slots. An arrow on each side of the mounting
slots shows you where to align the tractor.
When the tractor is positioned in the mounting slots
the lock tabs.
, release
Pull the paper-release lever forward to the pull-tractor
position.
You are now ready to load continuous paper. See page 2-15 for
instructions.
Paper Handling 2-11
