Panasonic TH-86CQE1W 86" Class 4K UHD Commercial Monitor - Manual (Page 24)

English - 23 -
To activate this function, a file named “playlist.txt”
should be installed on the USB storage device. Also,
the first line of the file must start with “//**do usb auto
play**//”.
Files which to be displayed/played must be written line
by line in playlist.txt. The “/* */” expression provides to
comment out the line. During playing content, only the
volume and standby buttons are used. EXIT/RETURN
buttons perform the exit operation.
Sample file content:
//**do usb auto play**//
video.mp4
/*picture3.jpg*/
video2.mp4
Scheduler playlist scenario
In this scenario, if the Source option is set as USB
while creating a scheduler, playlist options will be
displayed. The user can create 3 different playlists.
When the scheduler is activated, the playlist scenario
is started.
During the autoplay, the selected playlist will be
checked first. If the selected playlist is not available in
connected the USB storage device, the default playlist
file will be checked. If the default playlist file is not
found, it works just like the USB Auto play scenario.
Note: If EXIT/RETURN key input is received during
auto play, auto play may finish.
Image Search Feature
If No Signal option in the Settings>Signage>Controls
menu is set as Image Search the Display checks the
connected USB device for available files to play. If no
playable files are available or there is no USB device
connected to the Display, the No Signal image will
be displayed and the Display will turn itself off after a
period of No Signal Timer. If there isn’t any No Signal
Image available, No Signal OSD will be displayed on
the screen and the Display will turn itself off after a
period of No Signal Timer.
Note: If signal is detected in the current input source, No
Signal Image and No Signal OSD will disappear, but playing
the files in the USB device will be continued.
Note: The setting of the USB Auto Play option in the
Settings>System>More menu is not important, in Image
Search mode it will function anyway.
CEC and CEC RC
Passthrough
This function allows to control the CEC-enabled
devices, that are connected through HDMI ports by
using the remote control of the Display.
The
CEC option in the Settings>System>More
menu should be set as Enabled at first. Then, select
the HDMI input of the connected CEC device. When
new CEC source device is connected, it will be listed
in source menu with its own name instead of the
connected HDMI ports name(such as DVD Player,
Recorder 1 etc.).
The Display remote is automatically able to perform
the main functions after the connected HDMI source
has been selected. To terminate this operation and
control the Display via the remote again, press and
hold the “0-Zero” button on the remote control for 3
seconds.
You can disable the CEC functionality by setting the
related option under the Settings>System>More
menu accordingly.
Note: Depending on the display status or video
equipment status, such as during start-up, the
interlocking operation may not be performed.
Audio Return Channel
The Display supports ARC (Audio Return Channel).
This feature is an audio link meant to replace other
cables between the Display and an audio system (A/V
receiver or speaker system).
When ARC is active, the Display does not mute its
other audio outputs automatically. You will need to
decrease Display volume to zero manually if you
wish to hear the ARC audio only (same as optical or
co-axial digital audio outputs). If you want to change
connected device’s volume level, you should select
that device from the source list. In that case volume
control keys are directed to connected audio device.
Note : ARC can only operate with HDMI1.
System Audio Control
Allows an Audio Amplifier/Receiver to be used with the
Display. The volume can be controlled using the remote
control of the Display. To activate this feature set the
Speakers option in the Settings>System>More
menu as Amplifier . The Display speakers will be
muted and the sound of the watched source will be
provided from the connected sound system.
Note: The audio device should support System Audio Control
feature and CEC option should be set as Enabled .
