Page 11
English
- 10 -
General View
Front Side
1.
LCD Panel
Rear Side (1)
1
2
3
4
5
6
9
10
11
8
7
12
16
15
13 14
HDMI IN
HDMI IN
AUDIO
OUT
OUT
IR IN
D splayPort
1
4
3
2
IN
HDMI IN
HDMI IN
AUDIO
OUT
IR IN
1
4
3
2
SERIAL IN
USB-C
SQE1
CQE1
USB
USB
PC IN
LAN
5V 1.5A
5V 0.5A
5V 0.5A
1.
SERIAL IN
2.
PC IN
3.
LAN
4.
USB-C
5.
USB
6.
USB
7.
HDMI2 IN
8.
HDMI3 IN
9.
HDMI4 IN
10.
IR IN
11.
AUDIO OUT
12.
HDMI1 IN
13.
Internal USB Compartment
14.
Connector for SLOT (Only for SQE1W)
Note:
For the compatible function board, consult the
dealer where you purchased the product.
15.
DisplayPort IN (Only for SQE1W)
16.
DisplayPort OUT (Only for SQE1W)
