English - 22 -
4.1. Source Settings
Enable or disable selected source options. There
are also Regular , Enhanced and Disabled options
available for HDMI source. Regular and Enhanced
options are affecting the colour settings of the HDMI
source. To be able to watch 4K or HDR/HLG images
from the HDMI source its source setting should
be set as Enhanced if the connected device is
compatible with HDMI 2.0 and subsequent versions.
Set as Regular if the connected device is HDMI 1.4
compatible. Set accordingly or disable the HDMI
source by setting as Disabled .
You can reset your customizations on the Home and
Apps menus to defaults using the Reset Menu option
in the Settings menu. Highlight this option and press
ENTER . A confirmation message will be displayed.
Highlight Yes and press ENTER to proceed.
Media Playback via
USB Input
You can connect 2.5” and 3.5” inch (HDD with
external power supply) external hard disk drives or
USB memory stick to your Display by using the USB
input/s of the Display.
IMPORTANT! Back up the files on your storage
devices before connecting them to the Display.
Manufacturer will not be responsible for any file
damage or data loss. Certain types of USB devices
(e.g. MP3 Players) or USB hard disk drives/memory
sticks may not be compatible with this Display. The
Display supports FAT32 and NTFS disk formatting.
Wait a little while before each plugging and unplugging
as the player may still be reading files. Failure to do
so may cause physical damage to the USB player
and the USB device itself. Do not pull out your drive
while playing a file.
You can use USB hubs with your Display’s USB
input/s. External power supplied USB hubs are
recommended in such a case.
It is recommended to use the Display’s USB input/s
directly, if you are going to connect a USB hard disk.
Note: When viewing image files the Media Browser menu
can only display 1000 image files stored on the connected
USB device.
Media Browser Menu
You can play back music and movie files and display
photo files stored on a USB storage device by
connecting it to your Display. Connect a USB storage
device to one of the USB inputs located on the rear
side of the Display.
After connecting a USB storage device to your Display
Media Browser menu will be displayed on the screen.
You can access the content of the connected USB
device any time later from the Sources menu. Select
the related USB input option from this menu and press
ENTER . Then select the file of your choice and press
ENTER to display or play it back.
You can set your Media Browser preferences by
using the Settings menu. Settings menu can be
accessed via the information bar which is displayed on
the bottom of the screen when pressed the RECALL
button while playing back a video file or displaying
a picture file. Press the RECALL button, highlight
the gear wheel symbol positioned on the right side
of the information bar and press ENTER . Picture
Settings , Sound Settings , Media Browser Settings
and Options menus will be available. The contents
of these menus may change according to the type of
the currently open media file. Only Sound Settings
menu will be available while playing back audio files.
Loop/Shuffle Mode Operation
Start playback and activate
All files in the list will be contin -
uously played in original order
Start playback and activate
The same file will be played
continuously (repeat)
Start playback and activate
All files in the list will be played
once in random order
Start playback and activate
,
All files in the list will be con -
tinuously played in the same
random order.
To use the functions on the information bar highlight
the symbol of the function and press ENTER . To
change the status of a function highlight the symbol
of the function and press ENTER as much as needed.
If the symbol is marked with a red cross, that means
it is deactivated.
Note: The list in the Loop/Shuffle Mode consists of
the same type of media files in the same folder as
the playing file.
USB Auto Play Feature
USB AutoPlay feature is to start playing the media
content installed on a removable device, automatically.
Photo and Video contents in the root directory of the
removable device will be played in a sequence (in
file name order).
This feature will only work if all of the following
circumstances occur:
• The USB device is plugged in.
•
USB Auto Play option is enabled. It is placed in the
Settings>System>More menu.
USB Auto Play Feature with Playlist
Scenario
If there is a file named as “playlist.txt” installed on the
connected USB storage device, the new scenario is
started. The media content in this file will be played or
displayed according to the entered sequence.
