English - 21 -
Shipping
When turned on for the first time, the language
selection screen will be displayed. Select the desired
language and press ENTER .
On the next screen, set your country preference and
press ENTER to continue.
You will be asked to set and confirm a PIN at this point.
For some country options, the PIN cannot be set to
0000 , in this case you need to enter another 4-digit
number combination. You have to enter this PIN if you
are asked to enter a PIN for any menu operation later.
The
Set User Name and Password setting menu will
be displayed next.
Please press the password policy to check the contents
and make each setting.
The
Signage Settings menu will be displayed next.
Set ID , OSD Orientation , Auto Software Update
options can be configured using this menu. Model
name , Serial number and Software version options
are for information only. They will be grayed out and
not selectable. You can save the model information
data of the Display to a connected USB device using
the Save model information option. You can also
copy database files from a connected USB device to
the Display using the Clone from USB option. Refer
to the Signage Settings Menu Content section for
more information on the options of this menu. After
the settings are completed, highlight Next and press
ENTER to continue.
The Display Operation Mode will be displayed next.
Power Mode is set to "Eco" ; Turn the power on in a
usual manner at power-on.
Power Mode is set to "Reactive" ; Quickly turns the
power on at power-on.
(Note) When this function is set to "Reactive", the
power consumption is increased in standby mode.
The
Auto Launch Selection screen will be displayed
next. Open Browser and Disabled options will be
available. Highlight the desired option and press
ENTER to proceed.
On the next screen, the Network/Internet Settings
menu will be displayed. Please refer to Connectivity
section to configure a wired or a wireless connection.
If you want your Display to consume less power
in standby mode, you can disable the Networked
Standby Mode option by setting it as Off . After the
settings are completed highlight Next and press
ENTER button to continue.
The Shipping is completed.
To repeat this process and reset the Display's settings
to the factory defaults enter the Settings>Signage
menu, highlight Shipping and press ENTER . You will
be asked to enter the PIN that you have defined in
the First Time Installation. If the correct PIN is entered
a confirmation message will be displayed asking
whether you want to delete all settings and reset the
Display. Select Yes and press ENTER to confirm.
Note: Do not turn off the Display while initializing first time
installation. Note that, some options may not be available
depending on the country selection.
Note: If you forget the PIN, please contact the service company.
Note: The initial value of PIN is "0000".
Using Main Display
Menu
When the Menu button is pressed, the main Display
menu will appear at the left of the screen. You can
navigate through the menu items using the directional
buttons on the remote. To select an item or see the
sub-menu options of the highlighted menu press
ENTER button. When you highlight a menu option
some of the sub-menu items of this menu may appear
on the upper side of the menu bar for quick access.
To use a quick access item highlight it, press ENTER
and set as desired using the Left/Right directional
buttons. When finished press ENTER or EXIT/
RETURN button to exit.
Press EXIT button to close the main menu.
1. Home
When main menu is opened Home menu bar will
be highlighted. The content of the Home menu can
be customised by adding options from other menus.
Just highlight an option and press the Down direction
button on the remote. If you see Add to Home option
you can add it to the Home menu. Same way you can
delete or change the position of any item in the Home
menu. Press the Down direction button and select
Delete or Move option and press ENTER . In order
to move a menu item use the Right and Left direction
buttons to select the position that you want the item
to move to and press ENTER .
2. Settings
You can manage the settings of your Display using
the options of this menu. Refer to Settings Menu
Contents section for more information.
3. Apps
When your Display is connected to the Internet related
contents will also be available, including Apps related
contents. Using the Apps menu you can access
your applications. Refer to Apps section for more
information.
4. Sources
You can manage your input source references using
the options of this menu. To change the current source
highlight one of the options and press ENTER .
