English - 11 -
Rear Side (2)
DIGITAL AUDIO
OUT
SERVICE 2
R
L
AUDIO
IN
SERVICE 1
1
2
3
4
1. DIGITAL AUDIO OUT
2. AUDIO IN
3. RJ12 (SERVICE 1)
4. RJ12 (SERVICE 2)
Note : Don’t use except service personnel for RJ12.
Control Buttons on the Display
To turn on the Display: Press the centre of
the joystick in and hold it down for a few
seconds, the Display will turn on.
To turn the Display off: Press the centre
of the joystick in and hold it down for a few
seconds, the Display will turn into standby
mode.
To change source: Press the centre of the
joystick in, the sources list will appear on the
screen. Scroll through the available sources
by pushing the joystick up or down. After
selecting the source, push the joystick "+"
To change volume: Increase the volume
by pushing the joystick "+". Decrease the
volume by pushing the joystick "-".
Note: Main menu OSD cannot be displayed via joystick.
(rear view)
