English−92
PICTURE MENU
6 AXIS COLOR TRIM With these controls, the standard color circle is divided into 6 separate ranges/areas: Reds, Yellows,
Greens, Cyans, Blues, and Magentas. Each range can be individually adjusted in Hue, Saturation, and
Offset (Brightness) for specific matching purposes. Neutral colors (grays) will not be impacted.
RED (HUE/SAT./
OFFSET)
HUE: Changes the actual color within its range on the color wheel without changing the
saturation and offset. For example, the Red color range shifts reds towards Yellow or
Magenta, the Yellow color range shifts yellows towards Red or Green, and so on.
SAT. (Saturation): Changes the intensity of the color range without changing the hue and offset.
OFFSET:
Changes the brightness of the color range without changing the hue and saturation.
e.g.: This is the color changes when Red color set to minimum
value and maximum value at HUE/SAT./OFFSET.
Minimum value 0 Maximum value
Default
HUE
SAT.
OFFSET
YELLOW (HUE/SAT./
OFFSET)
GREEN (HUE/SAT./
OFFSET)
CYAN (HUE/SAT./
OFFSET)
BLUE (HUE/SAT./
OFFSET)
MAGENTA (HUE/SAT./
OFFSET)
UNIFORMITY This function improves the color reproduction and evens out the non-uniformity in luminance of the
monitor.
NOTE:
A higher number produces a better effect, but may also affect power consumption and lifetime of
the monitor.
BACKLIGHT DIMMING
When [SPECTRAVIEW ENGINE]
is set to [ON]
Automatically adjusts each of the clusters of the backlight of the LCD independently, according to the input
signal.
SPECTRAVIEW ENGINE
SPECTRAVIEW ENGINE Select [ON] to activate [SPECTRAVIEW ENGINE] (see page 45 ).
NUMBER OF PICT. MODES Limits the number of selectable Picture Modes.
Limiting the number of selectable Picture Modes can be used for the following purposes:
• Locking.
By setting to [1], it will prevent other Picture Modes from being accessed and adjusted.
• Skip.
If there are unused Picture Modes that aren’t needed, they can be skipped when using the Picture
Mode button on the remote control to toggle modes. For example, if [3] is set for [NUMBER OF PICT.
MODES], the available picture modes are [1, 2, 3] and the other modes will be skipped.
METAMERISM Improves the white point color matching when the display is used side-by-side with a standard gamut
display monitor. This feature compensates for the way the human eye perceives colors slightly differently
compared to the scientific instrument used to adjust the monitor during calibration. This function should be
disabled in color critical applications.
CALIBRATION Starts the “Stand-Alone Calibration” when using a USB color sensor. See page 49 .
