English−97
PICTURE MENU
ROTATE
Sets the multi-screen rotation.
NOTE:
• The POINT ZOOM function will not work if this function is enabled.
• This function is canceled when [DisplayPort VERSION] in [DisplayPort1] is set to [1.4] or
[SCREEN SAVER] is set to [MOTION] or [IMAGE FLIP] is set to [NONE].
• If input signal is Interlaced signal this function is disabled.
• If input is DisplayPort 4K (60 Hz) 10bit, this function is disabled.
ROTATE ALL
Rotate all pictures.
Rotates [PICTURE1].
Rotates [PICTURE2].
RESET
Resets all PICTURE settings back to factory settings except for [PICTURE MODE] and [SPECTRAVIEW
ENGINE].
*
1
: This function is only available when Raspberry Pi Compute Module Interface Board and Raspberry Pi Compute Module are installed. See
*
2
: This function depends on which Option Board you are using. This function is only available when Option Board is installed.
*
3
: This function is available only when connecting the optional sensor unit.
AUDIO
AUDIO MENU
AUDIO MODE
Provides pre-configured audio settings suitable for various environments where this device may be used,
or customize settings to viewer preference.
NATIVE: Standard setting.
RETAIL: Surround sound for clarity of audio in retail stores.
CONFERENCING: Optimized settings for clarity of audio in conference rooms.
HIGHBRIGHT: Lowest volume level in order to focus on the visual message (audio is mute in factory
setting).
TRANSPORTATION: Lowest volume level in order to avoid disturbance in public spaces (audio is mute in
factory setting).
CUSTOM: Customizable settings.
VOLUME
Increase or decrease output volume level.
BALANCE
Select [STEREO] or [MONO] for the audio output.
STEREO/MONO
STEREO: Independent audio channels for routing audio signal. Sound balance of the monitor’s internal
speaker or the external speaker connected to the monitor between the left and right can be adjusted.
- Press the
button to move the audio signal to the right.
- Press the
button to move the audio signal to the left.
MONO: Audio signals are routed through a single audio channel. Balance cannot be adjusted and the
slider will be unavailable.
SURROUND
Artificially produces surround sound audio.
EQUALIZER
TREBLE
Accentuates or reduces the high frequency range of audio signals.
Press the
button to increase [TREBLE].
Press the
button to decrease [TREBLE].
BASS
Accentuates or reduces the low frequency sound.
Press the
button to increase [BASS].
Press the
button to decrease [BASS].
