NEC M861 86" UHD 4K HDR Commercial Monitor - Manual (Page 23)

English−19
Attaching Mounting Accessories
Be careful to avoid tipping the monitor when attaching accessories.
1. Attach eyebolts for mounting
This model is equipped with pre-installed eyebolt brackets for attaching eyebolts (not included) to aid in mounting.
• Screw the eyebolts into eyebolt holes in eyebolt brackets as shown in the picture.
• Be sure the eyebolts are secure.
• In order to move the monitor into position, use a lifting device attached to the eyebolts.
CAUTIONN DO NOT mount the monitor using only the eyebolts. Eyebolts are for temporary use only.
M10
2. Attach Mounting Accessories
Be careful to avoid tipping the monitor when attaching accessories.
Mounting Interface (M8)
600 mm
400 mm
Mounting accessories can be attached with the monitor in the face down position. To avoid scratching the LCD panel, always
place a soft cloth, such as a blanket that is larger than the monitor’s screen area, on the table before laying the monitor face
down. Make sure there is nothing on the table that can damage the monitor.
NOTEN: Prior to installation, place the monitor face down on a flat even surface that is larger than the monitor screen.
Use a sturdy table that can easily support the weight of the monitor.
