English−82

M861

Product Specifications

LCD Module

Pixel Pitch:

Resolution:

Color:

Brightness*

6

:

Contrast Ratio:

Viewing Angle:

86”/217.43 cm diagonal

0.494 mm

3840 x 2160

Over 1073 million colors (depending on display card used)

500 cd/m

2

(max.)

1200:1

89° (typ) @ CR>10

Frequency

Horizontal:

Vertical:

15 - 135 kHz (HDMI)/22 - 264 kHz (DisplayPort1)/22 - 134 kHz (DisplayPort2)

23 - 76 Hz

Pixel Clock

25 - 600 MHz (HDMI)

25 - 2380 MHz (DisplayPort1)

25 - 570 MHz (DisplayPort2)

Viewable Size

1895.04 x 1065.96 mm

Input/Output Signal

DisplayPort

DisplayPort Connector

Digital RGB

DisplayPort (Up to 7680 x 4320 (60 Hz)*

1

, HDCP 1.3/2.2)

HDMI

HDMI Connector

Digital YUV

Digital RGB

HDMI (Up to 4096 x 2160 (60 Hz)*

1

, HDCP 1.4/2.2)

Audio terminal

AUDIO Input DisplayPort Connector

Digital Audio

PCM 32, 44.1, 48 kHz (16/20/24 bit)

HDMI Connector

Digital Audio

PCM 32, 44.1, 48 kHz (16/20/24 bit)

AUDIO

Output

Stereo Mini Jack

Analog Audio

Stereo L/R 0.5 Vrms

HDMI Connector (ARC*

2

) Digital Audio

PCM 32, 44.1, 48 kHz (16/20/24 bit)

Speaker Output

External Speaker Jack 15 W + 15 W (8 ohm)

Internal Speaker 10 W + 10 W (Stereo)

Control

RS-232C In:

LAN:

Remote IN:

9 Pin D-sub

RJ-45 10 BASE-T/100 BASE-TX x 2

Stereo Mini Jack 3.5 mm Ø

USB

USB-A

USB 2.0 Downstream port, DC 5 V/500 mA (max.)

USB-B

USB 2.0 Upstream port

SERVICE

Power supply port, DC 5 V/2 A (max.)

Firmware update port

Power Supply

6.6 - 2.6 A @ AC 100 - 240 V 50/60 Hz

Power

Consumption

Normal Operation*

5

:

Energy Saving Mode*

5

(LED glowing amber):

Energy Saving Mode*

5

(LED blinking amber):

Approx. 320 W

2 W or less

0.5 W or less

Operational Environment

Temperature*

3

:

Humidity:

Altitude:

0 - 40 °C / 32 - 104 °F

20 - 80 % (without condensation)

3000 m or less (Brightness may decrease with altitude)

Storage Environment

Temperature:

Humidity:

–20 - 60 °C / –4 - 140 °F

10 - 80 % (without condensation) / 90 % - 3.5 % x (Temp - 40 °C) regarding over 40 °C

Dimension*

4

1927.6 (W) x 1099.1 (H) x 88.4 (D) mm/75.89 (W) x 43.27 (H) x 3.48 (D) inches (with handle)

1927.6 (W) x 1099.1 (H) x 83.2 (D) mm/75.89 (W) x 43.27 (H) x 3.28 (D) inches (without handle)

Weight

Approx. 47.9 kg (105.6 lbs)

Tilt Angle

±15°

Mounting interface

600 mm x 400 mm (M8, 4 Holes)

Power supply for Option Board

12 V/5.5 A (max.)

Power supply for Raspberry Pi Compute Module

12 V/1.67 A (max.)

Power supply for Option Board and Raspberry Pi Compute Module 12 V/5.5 A (max.)

NOTEN Technical specifications are subject to change without notice.

*

1

: Compressed image.

*

2

: HDMI IN1 only.

*

3

: When you use Option Board accessories, please contact your supplier for detailed information.

*

4

: Measurements are of the monitor only and do not include removable parts that protrude.

*

5

: Without any option, with factory settings.

*

6

: The Brightness level changes depending on the input settings, picture settings, installation environment, and individual product characteristics.

The overall Brightness decreases as the product ages due to deterioration over time. It does not maintain a permanent brightness level throughout the product’s life.
