109
Setting Options Description
Nozzle Check Printless Nozzle Check Displays the nozzle
status on the LCD
screen.
Print Check Pattern Prints a nozzle check
pattern.
Head Cleaning Check and Clean Nozzle Checks the nozzle
status and cleans any
clogged nozzles.
All Nozzles Normal
Heavy
Lets you clean all or
selected nozzles based
on the nozzle check
pattern. Select
Normal
cleaning first. If nozzles
are still clogged, select
Heavy cleaning.
Select Nozzles
Various
colors
Head
Alignment Paper
Thickness Paper Type Lists supported media
types.
Paper Thickness Lets you set the
thickness of the loaded
paper.
Alignment Auto Uni-D
Bi-D 5-color
Bi-D All
Lets you align the print
head when print results
are grainy or out of
focus:
Uni-D : when printing in
one direction.
Bi-D settings: when
printing in both
directions. If head
alignment does not
correct the problem,
select
Uni-D .
Manual Uni-D
Bi-D 2-color
Bi-D All
