34
About functions that can be assigned to the
function buttons on this unit and the buttons 1 to
9 on the controller
Mono (black and white)
Press the button to display a monochrome
picture.
Blue Only
Press the button to eliminate the red and green
signals. Only the blue signal is displayed as an
apparent monochrome picture on the screen.
This facilitates observation of signal noise.
Native Scan
Press the button to switch between the image
with the scaling display (Off) and the image
displayed directly from pixels (On).
Notes
 When Native Scan (On) is selected, 2K
resolution signals are displayed while enlarged
horizontally and vertically with the following
proportion (repeating pixel values).
– 1280 × 720 signal: × 3
– Others: Ч 2
 640 Ч 480/60P, 720 × 480/60P, and 720 × 576/
50P signals for HDMI are not enlarged up to the
end of the display.
 When “Native Scan” is set to “On,” “Under
Scan” is set to “Off.”
Audio Muting
Press to mute audio output.
R Off
Press the button to turn off the R (red) signal.
G Off
Press the button to turn off the G (green) signal.
B Off
Press the button to turn off the B (blue) signal.
Internal Signal
Press the button to display the internal signal.
Int. Signal Pattern
Press the button to change the pattern of the
internal signal when the internal signal is
displayed. With every press of the button, the
picture switches to “Gray,” “White,” and “Color
Bars,” in this order.
Ch.1 to Ch.30
Press to switch to the assigned channel.
Note
In Quad View, a channel selected in the “Multi
View” menu is displayed regardless of the
operation and setting of the function buttons
and numeric buttons on the controller.
Marker
Press the button to display the aspect marker,
area marker 1, area marker 2, and/or center
marker with On selected.
Aspect Marker
Press the button to display the aspect marker.
Area Marker1
Press the button to display area marker 1.
Area Marker2
Press the button to display area marker 2.
Center Marker
Press the button to display the center marker.
Aspect Marker-Line
Press the button to display the line of the aspect
marker.
Asp. Blank.-Half
Press the button to set the aspect blanking to
half.
Asp. Blank.-Black
Press the button to set the aspect blanking to
black.
Note
The “Marker” to “Asp. Blank.-Black” settings are
not available in the following cases:
 When the input signal is No Sync signal
 When the internal signal is displayed
 When displayed in Quad View
Submenu Setting
F/Num Key Setting
F1 to F16
Numeric1 to
Numeric9 Assigns functions to the F1 to F16
buttons or buttons 1 to 9 on the
controller. For the functions available
for the function buttons on the
controller, see page 10. For the
functions available for the buttons 1 to
9 on the controller, see “About
functions that can be assigned to the
function buttons on this unit and the
buttons 1 to 9 on the controller”
(page 34).
