23
User Color Temp.
You can select and adjust the color temperature.
When using a measurement instrument for color
temperature adjustment, Konica Minolta Color
Analyzer CA-310/410 is recommended. Chr./Bright./Cont. Sets the chroma level, brightness, and
contrast for the selected channel.
(Default value: 1000/0/400)
Notes
 Press the function button to select
the item for adjustment. Pressing
the F9 button selects “Chroma,” F10
button selects “Brightness,” and F11
button selects “Contrast.” To set the
value of the selected item to the
median, press the F12 button.
 The brightness adjustment of “ITU-
R BT.2100(HLG)” supports the ITU-R
BT.2100-2 standard.
 The brightness adjustment of
“SMPTE ST 2084” supports the ITU-
R BT.814-4 standard.
 The brightness-adjustment
specifications of “S-Log3” and “S-
Log3(Live HDR)” are the same as
those of “SMPTE ST 2084.”
 When “EOTF” is set to “2.2,” “2.4,” or
“2.6,” the contrast control method
depends on the “Quad View
Display” setting located under
“Quad View” in the “Multi View”
menu. When “Quad View Display”
is “On,” the contrast is adjusted
with the signal level by fixing the
backlight brightness. When “Quad
View Display” is “Off,” the contrast
is adjusted by changing the
backlight brightness. Black levels
fluctuate to change the backlight
brightness.
User LUT Select the 3D LUT file to apply to a
picture.
 Off
 User LUT1 to User LUT30
Note
To apply the 3D LUT file, you need to
load the 3D LUT file to the monitor in
advance. For details, see “Loading 3D
LUT files to the monitor” (page 24).
Marker Preset Select the marker preset to be used for
the selected channel. You can select a
marker preset between “Preset1” and
“Preset10.”
Audio Preset Select the audio preset to be used for
the selected channel. You can select
an audio preset between “Preset1” and
“Preset10.”
Advanced Preset Select the advanced preset to be used
for the selected channel. You can
select an advanced preset between
“Preset1” and “Preset10.”
Copy From Copy another channel’s data to the
selected channel.
Submenu Setting
Submenu Setting
User Color Temp. Select the color temperature setting to
be adjusted.
Name Sets the color temperature name.
R/G/B Gain Adjusts the color balance (gain) of R
(red)/G (green)/B (blue).
R/G/B Bias Adjusts the color balance (bias) of R
(red)/G (green)/B (blue). (Default
value: 0)
Notes
 To select the color for adjustment,
press the corresponding function
button. Pressing the F9 button
selects “R,” F10 button selects “G,”
F11 button selects “B,” and F12
button selects “RGB.”
 In consideration of the LCD
characteristics, the internal signal
level is set as follows for this unit
when the color temperature is
adjusted.
When R/G/B Gain is adjusted:
Equivalent to 100 cd/m
2
When R/G/B Bias is adjusted:
Equivalent to 10 cd/m
2 (HDR),
Equivalent to 2.7 cd/m 2 (SDR)
When R/G/B Bias is adjusted, a
high internal signal level may cause
an error in the black level. Check
the black level with the PLUGE
signal, etc. after adjusting the color
temperature, and adjust the black
level under “Brightness” of “Chr./
Bright./Cont.” in “Ch. Setting” as
necessary.
