Acceptable Input Signals

Resolution

fH [kHz]/

fV [Hz]

Input terminal

INPUT A/

INPUT B

INPUT C/

INPUT D/

INPUT E

640 Ч 350

31.5/70

37.9/85

640 Ч 400

31.5/70

37.9/85

640 Ч 480

31.5/60

35.0/67

37.9/73

37.5/75

43.3/85

800 Ч 600

35.2/56

37.9/60

48.1/72

46.9/75

53.7/85

832 Ч 624

49.7/75

1024 Ч 768

48.4/60

56.5/70

60.0/75

68.7/85

1152 Ч 864

64.0/70

67.5/75

77.5/85

1152 Ч 900

61.8/66

1280 Ч 960

60.0/60

75.0/75

1280 Ч 1024

64.0/60

80.0/75

91.1/85

1400 Ч 1050

65.3/60

1600 Ч 1200

75.0/60

1280 Ч 768

47.8/60

1280 Ч 720

45.0/60

*1

1920 Ч 1080

67.5/60

*1

1366 Ч 768

47.7/60

1440 Ч 900

55.9/60

1680 Ч 1050

65.3/60

1280 Ч 800

49.7/60

1920 Ч 1200

74.0/60

*2

*2

1600 Ч 900

60.0/60

*2

*2

Signal

fV [Hz]

Input terminal

INPUT A/

INPUT B

INPUT C/

INPUT D/

INPUT E

INPUT F

*3

480i

60

576i

50

480p

60

576p

50

1080i

60

1080i

50

720p

60

*1

720p

50

1080p

60

*1

1080p

50

1080p

30

1080p

24

Notes
