31
The Connection/Power Menu
The Connection/Power menu is used for setting for the connections and power.
Setting items Description
Network Setting
IPv4 Setting
*1 *3
IP Address Setup Auto(DHCP): The IP address is assigned automatically from the DHCP server such as a
router.
Manual: To specify the IP Address manually.
IP Address/ Subnet Mask/
Default Gateway/Primary
DNS/Secondary DNS When “Manual” is selected for “IP Address Setup,” select the item with the  or  key and
input the value with  or  key. When all items are entered, select “Apply” then press the
ENTER key. The entered settings will be registered.
IPv6 Information Displays the IPv6 address information.
When setting the address of IPv6, set it from the browser (page 41).
HDBaseT Settings
LAN Setting via HDBaseT/LAN Port: You can select either via the LAN of the HDBaseT device
connected to the HDBaseT terminal or via the network connection with the LAN terminal of
the main unit.
*2 *3
RS-232C Setting via HDBaseT: You can connect this unit to the RS-232C terminal via the HDBaseT
transmitter. (Baud rate: 9,600 bps)
RS-232C: Use when connecting to the RS-232C terminal of this unit directly. (Baud rate:
38,400 bps)
Extron XTP On/Off: Set to “On” when connecting the HDBaseT terminal of this unit to XTP Systems
*4
manufactured by Extron Electronics. Set to “Off” when connecting to other equipment.
Dynamic Range
*5
Sets the image input level of the INPUT C/D/E/F terminal.
Auto: Distinguishes the image input level automatically.
Limited: Set when the image input level is 16-235.
Full: Set when the image input level is 0-255.
HDMI Cable Long/Normal: Select “Long” when the image is disturbed or not projected.
Input-A Signal Sel. Auto/Computer/Video GBR/Component: When set to “Auto,” selects the type of video
signal input automatically when “Input-A” is selected with the INPUT key.
*6
Input-G Cont. Sel. USB/Network: Sets the content for the HTML viewer. You can select “USB” or “Network” to
load a file (page 43).
ECO
Auto Power Saving
*7
With No Input Light Cutoff: The light turns off automatically and power consumption is reduced if no
signal is input for about two minutes. The light turns on again when a signal is input or any
key is pressed. In Light Cutoff, the ON/STANDBY indicator lights in orange (page 46).
Standby
*8
: If no signal is input to the unit for about two minutes, the power turns off
automatically, and the unit enters standby mode.
Off: The “With No Input” function is disabled.
With Static Signal Light Dimming
*9 *10
: If an image does not change for about 10 seconds, light output is
gradually reduced (approximately 10% to 15%
*11
) from that set in the Light Output Mode.
This setting provides a convenient way to reduce power consumption. In addition, the light
automatically darkens slowly to approximately 30% of its light output if the selected time
(
“5 min.,” “10 min.,” “15 min.,” “20 min.,” or “Demo.” ) elapses with no change to input
signal. While dimming the light, the message “Light Dimming” appears. If you select
“Demo.,” the image will start to darken about 40 seconds later. When any change in signal
is detected, or an operation (Remote Commander or control panel) is performed, normal
brightness is restored.
Off: The “With Static Signal” function is disabled.
Standby Mode *12 Standard/Low: When set to “Standard,” power consumption becomes higher in Standby
mode. For details, see “Power consumption (Networked Standby Mode)” in “Specifications”
(page 54).
