Panel Descriptions
˙ Rear Panel
Connect pedals and USB flash drive.
* To prevent malfunction and equipment failure, always turn down the volume, and turn off all the units before making any connections.
*1 When operating the pedal, take care not to pinch your fingers between the moving part and the body of the unit. Pay special attention to this when using the unit where
children are present.
Place the AC adaptor so the side
with the indicator (see illustration)
faces upwards. The indicator will
light when you plug the AC adaptor
into an AC outlet.
1 2
3
4 5 6 7 8 9
Computer USB flash drive
Cord hook
AC outlet
Power cord
AC adaptor
Indicator
Place the AC adaptor so
the side with the indicator
(see illustration) faces
upwards.The indicator will
light when you plug the AC
adaptor into an AC outlet.
1 2
3
4
5
6 7 8 9
10
Pedal
DP-10 (*1)
Sold separately: KPD-90, RPU-3, EV-5
Dynamic microphone Audio player Amplified speakers
Computer USB flash drive
AC outlet
Power cord
Indicator
Cord hook
AC adaptor
Use the cord hook to
secure the cord of the
AC adaptor as shown in
the illustration.
