MegaRAID SAS RAID Controllers User’s Guide 2-1
Copyright © 2005-2007 by LSI Logic Corporation. All rights reserved.
Chapter 2
MegaRAID SAS
Hardware Installation
This chapter describes the procedures used to install the
MegaRAID Serial Attached SCSI/Serial ATA II RAID controllers with
internal and external connectors. It consists of the following sections:
•
Section 2.1, “Requirements”
•
Section 2.2, “Quick Installation”
•
Section 2.3, “Detailed Installation”
•
Section 2.4, “SAS Device Cables”
•
Section 2.5, “Replacing a Failed Controller Containing Data in the
intelligent Transportable Battery Backup Unit 02”
•
Section 2.6, “After Installing the RAID Controller”
2.1 Requirements
The following items are required to install a MegaRAID SAS RAID
controller:
•
One of the following RAID controllers: SAS 8204ELP, SAS 8208ELP,
SAS 8204XLP, SAS 8208XLP, SAS 8300XLP, SAS 8304ELP, SAS
8308ELP, SAS 8344ELP, SAS 8408E, SAS 8480E, or SAS 84016E
•
A host system with an available PCI Express or PCI-X expansion slot
•
The MegaRAID Universal Software Suite CD, which contains the
drivers and documentation
•
The necessary internal cables, external cables, or both
•
SAS physical drives or SATA II physical disks
Note: LSI Logic strongly recommends using an uninterruptible
power supply (UPS).
