MINOURA P-500AL-5S - Manual

P-500AL-5S "PairStand"
instructions manual
(ver.5.2 2015/5)
!
FEATURES
● Save vast amounts of space by storing
two bicycles in a single space.
● Alloy pillar is light weight and rust proof,
but durable. Max load is 100 kgs.
● Legs are switchable between K-style
and X-style depending on the number of
bikes or setup location.
● Updated alloy clamp securely holds
the cradle and allows for easy position
changes.
● The bike hook is designed to be low
profile to get the bike on and off easily.
Soft plastic pads prevent frame from
being scratched. It fits up to 70mm
diameter frame.
● Individually angle adjustable arm fits any
type of bike frame.
CAUTIONS
● For normal 2-wheel bicycle only. Tandem,
recumbent and long tail bikes may not be
used on this stand. Place heaviest bike in the
lower cradle to maintain stands balance.
● Set stand on an even, horizontal floor. Adjust
each foot precisely to insure each of the
foot's four points touch the floor evenly.
● Leaving a bike in the top cradle only may
cause an imbalance and the stand could fall
down. Be careful to keep weights balanced
at all times.
● Do not hook the bike with the down-tube and
seat-tube. Hook the top-tube.
(Image: P-500AL-5S in K-style leg)
● The clamp is made of light alloy material. Do not over- tighten or the bolt may come out of the housing, ruining the
clamping mechanism.
● Follow the correct order for tightening the screws. Failure to do so may lead to improperly tightened screws.
● When you setup the legs in K-style, the stand should be placed next to a wall to prevent the stand from tipping over
backwards. Do not install any optional attachment on the backside of the pillar to maintain a safe balance.
When you setup the legs in X-style, these won't be a problem.
Contact
MINOURA JAPAN MINOURA NORTH AMERICAN TECH CENTER
(for ALL customers, including Canada) (for U.S. residents ONLY)
1197-1 Godo, Anpachi, Gifu 503-2305 Japan Mon - Fri, 9 am - 5 pm (PCT)
Fax +81-584-27-7505 Phone 1-510-538-8599 / Fax 1-510-538-5899
[email protected] / www.minoura.jp [email protected]
If you have question or problem on this product, please contact the shop where you originally purchase this product
or the distributor in your country first. The distributor information can be found on our web site. Only when you
cannot obtain enough service from them, you can contact Minoura directly.
Made in Japan
