Aurorean Network Gateway-1000 User’s Guide

Chapter 3

Configuring the ANG-1000 with Aurorean Web Config

H Click the Manual assigned IP address radio button and perform

the following steps:

–

Set the ANG-1000’s IP address.

–

Set the Subnet mask.

–

Optional. Click the DHCP server enabled box if the server is

up and running.

–

Set the Starting IP address of the range of consecutive IP

addresses you will create for this ANG-1000.

–

Set the total Number of IP addresses the ANG-1000 can

distribute.

–

Optional. Keep Enable DNS proxy checked so that the

ANG-1000 will act as a DNS server for all its tunnels. DNS

proxy resolves host names and IP addresses because the

domain server is non-routable, forcing attached hosts to

request these values. If your hosts know the DNS address

they are seeking, you can disable this feature. This option is

on by default.

–

Optional. Keep Enable WINS proxy checked so that PCs on

the LAN can be notified of WINS servers discovered during

tunnel setup. WINS proxy notifies local PCs of the remote

WINS servers without manual intervention. This option can

be disabled if local PCs already know remote WINS server IP

addresses. This option is on by default.

–

Click Apply.

CAUTION

If you change the default LAN Setup and reboot the ANG-1000, you must

release and renew the IP address for all adaptors bound to TCP/IP on
your connected computer(s) in order to reconnect with the ANG-1000
and make future changes. Perform the following steps:

- On your desktop, click Start. and Run.
- For Windows 95/98/ME systems, type: winipcfg, click OK, click

Release and click OK. Then click Renew All and click OK.

- For Windows NT/2000 systems, type ipconfig /release and press

NTER

. Then type ipconfig /renew and press

NTER

- For Macintosh systems, check the TCP-IP control panel.

If you chose the DHCP option or changed the DNS or WINS default
entries, a window appears detailing the reconfiguration changes and
prompting you to reboot the ANG-1000. Click Reboot Now.
