Aurorean Network Gateway-1000 User’s Guide
15
Chapter 3
Configuring the ANG-1000 with Aurorean Web Config
Downloading the Latest Firmware
After logging in, download the latest firmware image to the ANG-1000’s flash
memory (provided the MAC address is set for cable service users - refer to
page 32) by accessing the FTP server where it is stored. As new firmware
becomes available, you can update it again. Begin updating your firmware by
performing the following steps:
1 Click the Firmware Upgrade menu option.
The Firmware Upgrade window appears as shown in Figure 16.
Figure 16 Firmware Update Window
2 In the FTP server field, enter the name of the FTP server where the
new ANG image is stored: ang.enterasys.com.
3 Type the full path of the location of the Firmware image:
/ang1000/ANG1000.bin
4 Enter the Username anonymous
5 Enter netadmin in the Password and Confirm fields and click Apply.
The Firmware Update window appears as shown in Figure 17.
6 Click Apply and watch the External/Trusted LEDs on the front panel
blink displaying an inside/outside pattern.
The image is downloaded for15-30 seconds and loaded in flash
memory for another 30-45 seconds. If the LEDs do not blink or only
for a very short interval, the download failed and you must try again.
Aurorean Network Gateway 1000
Firmware Update Help
VPN Status
VPN Setup
VPN
Connectivity Setup
Internet Setup
LAN Setup
Firewall Setup
FTP server:
Firmware image
filepath:
Username:
Password:
Confirm:
Apply
