8 reboot the ang-1000 by clicking reboot now – Enterasys Networks ANG-1000 User Manual
Page 29
Aurorean Network Gateway-1000 User’s Guide
17
Chapter 3
Configuring the ANG-1000 with Aurorean Web Config
7
After downloading and “flashing “are complete, a status page displays
as shown in Figure 18 indicating the process was successful and
displaying the FTP server IP address and new build filepath.
Figure 18 Successful Firmware Update Window
8
Reboot the ANG-1000 by clicking Reboot Now.
The ANG-1000 will take a few moments to accept the new software.
9
To ensure that the image was updated, compare the date last
modified, Release, Build and Patch numbers in the lower left corner
of the VPN Status window as shown in Figure 15 with the previous
release information. The Device Status window also lists this data.
Figure 19 Image Date and Build Information
Help
VPN Status
VPN Setup
VPN
Connectivity Setup
Internet Setup
LAN Setup
Firewall Setup
ANG-1000 System
Set Password
Device Status
Firmware Update
Advanced Utilities
Links
Aurorean Network Gateway 1000
The Aurorean Network Gateway 1000 has been updated with the changes you
have selected. The following list shows the modifications that have been made:
Download new firmware image
FTP server: 146.34.69.128
Filepath: NewBuild/Build87/ANG1000-1.0.00-87.bin
Username: anonymous
The Aurorean Network Gateway 1000 needs to be rebooted in order to run with
the changes you have selected. Press the “Reboot Now” button below to reboot
the ANG-1000.
< Reboot Now Firmware Update Aurorean Network Gateway Release 1.0 Patch 00 Build 135 (3.3.1) 2001 Enterasys Networks. All rights reserved
Page last modified Wed Apr 13 16:52:37 EST 2001
