Instruction Manual
Appendix A Rev. 3.8
July 2002
A-0 Appendices
Rosemount Analytical Inc. A Division of Emerson Process Management
World Class 3000
2
3
NOTE: NOT ALL PARTS SHOWN ARE AVAILABLE FOR
PURCHASE SEPARATELY. FOR LIST OF
AVAILABLE PARTS, SEE TABLE A-3.
29
1
27
28
25
24
26
20
19
17
7
8
15 13
16
18
23
22
10
11
21
20
11
14
12
10
9
4
5
6
NOTE: ITEM
, CALIBRATION GAS TUBE,
FITS INTO HOLES
WHEN PROBE IS
ASSEMBLED.
21240005
APPENDIX A
1. Heater, Strut, and Backplate Assembly
2. Diffusion
Assembly
3. Retainer
Screw
4. Cell and Flange
5. Corrugated
Seal
6. Probe Tube Assembly
7. Screw
8. Washer
9. Cover Chain Screw
10. Cover
Chain
11. Probe Junction Box Cover
12. Cover
Gasket
13. Wiring
Diagram
14. O-Ring
15. Terminal Block Screws
16. Terminal
Block
17. Terminal Block Marker
18. Terminal Block Mounting Plate
19. Probe Junction Box Screws
20. Hose
Clamp
21. Hose
22. Gas
Connection
23. Seal
Cap
24. Label
25. Probe
Junction
Box
26. Ground
Wires
27. Insulating
Gasket
28. Washer
29. Screw
Figure A-1. Oxygen Analyzer (Probe) Exploded View
