Page 614: 6 optional bloc k skip 16.6 optional block skip

background image

614

Test Run and Program Run

16.6 Optional Bloc

k Skip

16.6 Optional Block Skip

Application

In a test run or program run, the control can skip over blocks that begin
with a slash “/”:

U

To run or test the program without the blocks

preceded by a slash, set the soft key to ON.

U

To run or test the program with the blocks preceded

by a slash, set the soft key to OFF.

Erasing the “/” character

U

In the Programming and Editing mode you select the block in which
the character is to be erased

U

Erase the “/” character

This function does not work for TOOL DEF blocks.

After a power interruption the control returns to the most
recently selected setting.
