New functions with 340 49x
-05
18
„ New Cycle 241 for Single-Fluted Deep-Hole Drilling (see User’s
Manual for Cycles)
„ Touch probe cycle 404 (SET BASIC ROTATION) was expanded by
parameter Q305 (Number in table) in order to write basic rotations
to the preset table (see User's Manual for Cycles)
„ Touch probe cycles 408 to 419: The TNC now also writes to line 0
of the preset table when the display value is set (see User's Manual
for Cycles).
„ Touch probe cycle 416 (Datum on Circle Center) was expanded by
parameter Q320 (safety clearance) (see User's Manual for Cycles)
„ Touch probe cycles 412, 413, 421 and 422: Additional parameter
Q365 (type of traverse) (see User's Manual for Cycles)
„ Touch probe cycle 425 (Measure Slot) was expanded by parameters
Q301 (Move to clearance height) and Q320 (setup clearance) (see
User's Manual for Cycles)
„ Touch probe cycle 450 (Save Kinematics) was expanded by input
option 2 (Display saving status) in parameter Q410 (mode) (see
User's Manual for Cycles)
„ Touch probe cycle 451 (Measure Kinematics) was expanded by
parameters Q423 (number of circular measurements) and Q432 (set
preset) (see User's Manual for Cycles)
„ New touch probe cycle 452 (Preset Compensation) simplifies the
measurement of tool changer heads (see User's Manual for Cycles)
„ New touch probe cycle 484 for calibrating the wireless TT 449 tool
touch probe (see User's Manual for Cycles)
