ND 1200 QUADRA-CHEK 67
1
.8 Pr
ogr
amming
Deleting a program step
Program steps can be deleted to simplify programs or to remove
unwanted steps. Any program step can be deleted, including program
property and ND 1200 settings steps.
To delete a step:
U Use the ARROW CURSOR keys to highlight the desired step.
U Press the CANCEL key.
Example of deleting a step
In this example, a probing step will be deleted from a circle
measurement:
To delete the step:
U Use the ARROW CURSOR keys to highlight the Circle
measurement step.
U Use the ARROW CURSOR keys to highlight a probing step.
U Press the CANCEL key to delete the step.
U Press the FINISH key to save to change and return to the Programs
screen.
Use care when deleting program steps, and store a
backup of the program first. Deleted steps cannot be
restored.
The circle measurement is highlighted The probing step is highlighted within
the circle measurement The CANCEL key is pressed and the
probing step is deleted
