Specifications
Housing ND 760 E
Cast-metal housing
Dimensions (W • H • D)
281 mm • 205 mm • 97.5 mm
Oper. temperature 0° to 45° C (32° to 113° F)
Storage temperature –20° to 70° C (–4° to 158° F)
Weight
Approx. 2.3 kg (5 lb)
Relative humidity <75% annual average
<90% in rare cases
Power supply 100 Vac to 240 Vac (-15 % to +10 %)
50 Hz to 60 Hz (± 2 Hz)
Power consumption 15 W
Protection IP40 as per EN 60 529
Encoder inputs For encoders with 7 to 16 µA PP
Grating period 2, 4, 10, 20, 40,
100, 200 µm and 12.8 mm
Reference mark evaluation for
distance-coded and single
reference marks
Input frequency Max. 100 kHz for 30 m (98.5 ft)
cable length
Display step Adjustable
(see “Linear Encoders”)
Datums 9 (nonvolatile)
Functions - 7 switching outputs
- Scaling factor
- Probing functions
- MIN position display
- Add key for erosion depth
- External set to zero
Specifications
