Connections on rear panel – HEIDENHAIN ND 760 E User Manual
Page 26
27
Power switch
ID label
Connections
on
Rear
Panel
Protective ground
Encoder inputs X1 to X3
Connections on Rear Panel
Power input
The interfaces X1, X2, X3, and X10 comply with the requirements for electrical separation according to EN 50178!
Switching inputs/
Switching outputs
Bateil2.pm6
27.03.2002, 12:04
27
