P41.1 to P41.3 Linear axis error compensation
Input range (µm):
-99999 to +99999
Factory default setting: 0
Example: Displayed length Ld = 620.000 mm
Actual length (as determined for example with
the VM 101 from HEIDENHAIN)
La = 619.876 mm
Difference DL = L a – L d = – 124 µm
Compensation factor k:
k = DL/Ld = – 124 µm/0.62 m = – 200 [µm/m]
P48.1 to P48.3 Activate axis display
Axis display active
AXIS ON
Not active AXIS OFF
P70Number of datum points
2 datum points
2 DATUM PT.
9 datum points 9 DATUM PT.
Function of the CL key
Set to zero with CL
CL....RESET
No set to zero with CL CL......OFF
P98 Conversational language 1)
German
LANGUAGE DE
English LANGUAGE EN
French LANGUAGE FR
Italian LANGUAGE IT
Dutch LANGUAGE NL
Spanish
LANGUAGE ES
Danish LANGUAGE DA
Swedish LANGUAGE SV
Finnish LANGUAGE FI
Czech
LANGUAGE CS
Polish LANGUAGE PL
Hungarian LANGUAGE HU
Portuguese LANGUAGE PT
P43.1 to P43.3 Reference marks
One reference mark
SINGLE REF. M.
Distance-coded with 500 • SP 500 SP
Distance-coded with 1000 • SP
1000 SP
Distance-coded with 2000 • SP 2000 SP
Distance-coded with 5000 • SP 5000 SP
(SP: signal period)
P44.1 to P44.3 Reference mark evaluation
Evaluation
REF. X ON
No evaluation
REF. X OFF
P45.1 to P45.3 Encoder monitoring
Amplitude and frequency
monitoring ALARM ON
No monitoring ALARM OFF
