P24 CODE 3
Code value for trigger point A3 (1st trigger point before
erosion depth)
Input range:
0 to 15
Default setting:
0
P25 CODE 4
Code value for trigger point A4 (2nd trigger point before
erosion depth)
Input range:
0 to 15
Default setting:
0
Example: 1st trigger point before erosion depth P24 = 10;
Value
8
4
2
1
Binary value
1
0
1
0
= decimal value 10
Output
A7 A6 A4 A3
Transistor conductive
X
X
Transistor locked
X
X
Definition:
Bit = 0 ........output transistor conductive
Bit = 1 ........output transistor locked
P30.1 to P30.3 Counting direction
Positive counting direction with
positive direction of traverse
DIRECT. POS
Negative counting direction with
positive direction of traverse
DIRECT. NEG
P31.1 to P31.3 Signal period of the encoder
Input range:
0.00000001 to 99999.9999 µm
Default setting:
10 µm
P33.1 to P33.3 Counting mode
0 - 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9
0 - 2 - 4 - 6 - 8
0 - 5
P38.1 to P38.3 Decimal places
2 / 3 / 4 / 5 / 6 / 7 / 8 (up to 8 with inch display)
P40.1 to P40.3 Select type of axis error compensation
No axis error compensation
COMP. OFF
Linear error compensation active,
multipoint error comp. not active
COMP. LIN
Multipoint error compensation active,
linear error compensation not active COMP. MULTI
Operating
Parameters
