Kayenne XL Package — Installation and Service Manual
85
Kayenne XL Cabling
Figure 59. Assignment of the Panel Stripe Connectors
1-ME 15 Control Panel
2-ME 25 Control Panel
3-ME 35 Control Panel
Optional
Module
4-ME 35 Control Panel
Optional
Module
Optional
Module
PCU Port 2
PCU Port 3
PCU Port 2
PCU Port 1
PCU Port 5
PCU Port 3
PCU Port 2
PCU Port 1
PCU Port 4
PCU Port 2
PCU Port 1
PCU Port 3
PCU Port 1
PCU Port 4
