Pcu diagnostics – Grass Valley Kayenne XL Package Installation v.7.0.4 User Manual
Page 194
194
Kayenne XL Package — Installation and Service Manual
Section 5 — Maintenance
PCU Diagnostics
Figure 185. PCU Status Display
During the BIOS pre-boot process the status displays will show the post
code checkpoints.
Please note that checkpoints may differ between different platforms based
on system configuration.
In case of error please note the checkpoints and contact your Grass Valley
service personnel.
OFF
ON
Control Panel Processor
Reset Button
Menu Panel
Reset Button
Second Menu Panel
Reset Button (option)
PCU Frame
Power Switch
8623266_66
4-digit Status Display
