Kayenne XL Package — Installation and Service Manual
Section 3 — Kayak HD Frames
8-RU Frame Rack Mounting
Figure 41. Kayak HD 8-RU Frame Dimensions
CAUTION Mounting using only the front rack ears is sufficient for fixed installations.
Additional support, like the rear rack support or slide rails, is required for
mobile applications.
The Rear Rack support provides additional support and stability for the
Kayak HD frame to ensure that it remains horizontal.
Air
Intake
Rear Rack
Support
Air
Exhaust
8451_14_r1
