27
Kaleido-X16
Hardware Description & Installation Manual
Audio I/O
The Kaleido-X16 frame supports one SDTI audio input.
The Kaleido-X16 supports audio monitoring through its HD-26 connector. The supported
formats are the AES3 digital audio, and analog audio.
Formats 720p59.94
1080i50
1080i59.94
1080PsF23.98
1080PsF24
1080PsF25
1080PsF29.97
1080p23.98
1080p24
1080p29.97
Cable length 100 m (328 ft) (Belden 1694A)
Return loss >15 dB up to 1.5 GHz
Additive jitter < 0.2 UI p-p (wideband)
Connector BNC
3G-SDI Router Outputs
Signal 4:2:2 SMPTE ST 424:2006 (2.97 Gbps / 2.97/1.001 Gbps)
Formats 1080p50
1080p59.94
Cable length 100 m (328 ft) (Belden 1694A)
Return loss >15 dB up to 1.5 GHz + 10 dB up to 2.97 GHz
Jitter < 0.3 UI p-p (wideband)
Connectors BNC
HD-SDI Router Outputs (continued)
SDTI Audio Input
Signal SMPTE ST 305 (up to 128 channels/64 AES)
Cable length 250 m (820 ft) (Belden 1694A)
Connector BNC
