26
Specifications
Router Outputs
Router Outputs
The Kaleido-X16 frame supports two 3G/HD/SD-SDI router outputs.
Cable length 100 m (328 ft) (Belden 1694A)
Jitter < 0.2 UI p-p
Connectors BNC
3G-SDI Monitoring Outputs
Signal 4:2:2 SMPTE ST 424:2006 (2.97 Gbps / 2.97/1.001 Gbps)
Formats (Level A only) 1080p50
1080p59.94
Audio SMPTE ST 299-1 (limited to one pair, embedded on group 1,
pair 1)
Cable length 100 m (328 ft) (Belden 1694A)
Return loss > 15 dB up to 1.5 GHz
> 10 dB up to 2.97 GHz
Quantization 8 bits
Jitter < 0.3 UI p-p
Connectors BNC
HD-SDI Monitoring Outputs (continued)
SD-SDI Router Outputs
Signal 4:2:2 SMPTE ST 259-C (270 Mbps), SMPTE ST 272:1994
Formats 525 and 625
Cable length 225 m (738 ft) (Belden 1694A)
Return loss >15 dB up to 270 MHz
Additive jitter < 0.2 UI p-p (wideband)
Connector type BNC
HD-SDI Router Outputs
Signal 4:2:2 SMPTE ST 292-C (1.5 Gbps)
