23
Specifications
This chapter lists equipment specifications for the Kaleido-X16 multiviewer.
Inputs
Video Signal Inputs
The Kaleido-X16 frame supports 16 signal inputs. The supported input types include
Composite, SD/SDI, HD-SDI, and 3Gbps (auto-detected). The processing delay is two fields if
the video inputs are genlocked, and two or three fields if the video inputs are not
genlocked. Signal inputs require BNC connectors.
Composite Inputs
Signal NTSC (SMPTE ST 170), NTSC-J, PAL-BGDHI, PAL-N, PAL-M, SECAM
Return loss > 30 dB up to 5.75 MHz
Quantization 8 bits
SD-SDI Inputs
Signal 4:2:2 SMPTE ST 259-C (270 Mbps)
Formats 525 and 625
Audio SMPTE ST 274:1994
Cable length 225 m (738 ft) (Belden 1694A)
Return loss >15 dB up to 270 MHz
Jitter < 0.2 UI
HD-SDI Inputs
Signal 4:2:2 SMPTE ST 292-C (1.5 Gbps)
