Outputs
Mosaic Outputs
The Kaleido-X16 frame supports two progressive scan HDMI outputs.
The Kaleido-X16 frame supports two 3G/HD-SDI monitoring outputs (with embedded
audio).
H frequency 37 kHz to 96 kHz
Refresh rate 50/59.94 Hz
Cable length 3.6 m (12 ft) with Altinex CB4012DV
Connector DVI-I (dual link)
HDMI Outputs
Signal DVI-D
Resolution From 1024 × 768 to 1920 × 1200 NI (all progressive scan)
H frequency 37 kHz to 96 kHz
Refresh rate 50/59.94 Hz
Cable length 5 m (15 ft)
1
1.Depending on the selected output resolution, on your display monitor’s tolerance, and on the
quality of the HDMI cable itself, a longer cable could be used, as long as the signal integrity is
maintained between the multiviewer, and the display monitor. For example, with a 1080p output
resolution, longer high-speed HDMI cables may require an HDMI booster.
Connector HDMI
Supported cable types HDMI to HDMI, or HDMI to DVI-D
HD-SDI Monitoring Outputs
Signal 4:2:2 SMPTE ST 292-C (1.5 Gbps)
Formats 720p59.94
1080i50
1080i59.94
1080PsF23.98
1080PsF24
1080PsF25
1080p23.98ß
1080p24
1080p29.97
Audio SMPTE ST 299-1 (limited to one pair, embedded on group 1,
pair 1)
