LDK 5417 + LDK 4417 User’s Guide | DC/DC converters 41
11 DC/DC converters
These converters, which are available as an option, are attached to the camera baseplate.
The can be used to supply teleprompters for example. They provide a regulated voltage of
12 V or 24 V (depending on converter type) and a power of 50 W. The maximum power
produced by the converter is ensured with a maximum triax length of :
• Type A triax (diameter 9 mm): 90 metres.
• Type B triax (diameter 13 mm): 150 metres.
LDK 5930 is the 12V version; LDK 5940 is the 24V version.
Figure 1-14. DC/DC converter
Attaching screws to the
camera baseplate or
optional fixing plate
177
131
11
0
All dimensions in mm
