Grass Valley LDK 5417 User Manual
Page 34
LDK 5417 + LDK 4417 User’s Guide | Base Station
22
5.
Tighten both the 3 mm dia. screws using the screwdriver to attach the front cover.
6.
Place both Base Stations side by side.
7.
Tighten the six 4 mm dia. screws with the screwdriver from inside the Base Station
to the left (power supply unit removed).
8.
Place both Base Stations in the 19" rack at the required location and attach it using
both lugs.
2 screws F/90 M3x4
6 screws F/90HC M4x5
allen wrench
