LDK 5417 + LDK 4417 User’s Guide | Configuration
6
2.2
Connecting a control panel
An OCP 400/10 operational control panel can be connected to the Base Station using an
serial (RS-422) link. Refer to the user’s guides of your camera and the OCP 400/10 for
more information about the functions that are available.
Powering the control panel
The recommend method to power the OCP 400/10 is to use a remote control cable
mentioned in chapter 1.4. The control panel is powered by the Base Station via the remote
control cable.
It is also possible to use an external power supply. The Grassvalley LDK 5903/00 external
power supply can provide for up to five operational control panels. In this case, any
standard RS-422 cable can be used to connect to the Base Station.
