LDK 5417 + LDK 4417 User’s Guide | Specifications 3
1.4.2 Custom length cables
To create your own custom length RS-422 remote control cable use the following wiring
diagrams (for cable runs up to 50m or 100m respectively):
Figure 1-1. RS-422 serial cable type 1 (twisted pair; 0 to 50 m)
Figure 1-2. RS-422 serial cable type 2 (twisted power; 0 to 100 m)
Base Station OCP 400/10
Ground
Ground
Return A
Return B
Out B
Out A
Ground
Ground
OCP power
(+ On Air 1,
On Air 2)
Ground
Out A
Out B
Return B
Return A
Ground
Ground
OCP Power
(+ On air1,
On AIR 2)
Ground
5
4
3
2
1
6
7
8
9
5
4
3
2
1
6
7
8
9
Cable Shield
Base Station OCP 400/10
Ground
Return A
Return B
Out B
Out A
Ground
OCP Power
(+ On Air1,
On Air2)
Ground
Out A
Out B
Return B
Return A
Ground
OCP Power
(+ On Air1,
On Air 2)
5
4
3
2
1
6
7
8
9
5
4
3
2
1
6
7
8
9
Cable Shield
