Customize Your CONTROL Center Page 33
Setting Camera Movement Parameters
Subject Position Menu Display Path: MENU > AUTOTRACK > SUBJECT POSITION
This menu enables you to offset the Centered or Sensor References relative to the center of
the picture. The entire window can be shifted up or down and left or right.
• Up, Down, Left, and Right Function Command Buttons: Move the tracking
window in the respective direction.
• PAN Range: +/- 4600 (approximately +/- 20°).
• TILT Range: +/- 2300 (approximately +/- 10°).
• The
CONTROL Center joystick can also be used to make these adjustments.
Use caution when adjusting Pan/Tilt windows and Subject Position. It is possible to
adjust the windows so that the presenter is off the screen.
Sensitivity Menu Display Path: MENU > AUTOTRACK > SENSITIVITY
Used to adjust the speed with which the CameraMan returns the presenter to the Subject
Position setting.
• Up/Down Keys: Adjust sensitivity up or down.
• Range: 10-120, in steps of 10 (10= slow).
Custom Views Menu Display Path: MENU > AUTOTRACK > CUSTOM VIEW
Used to store or recall up to 10 autoTRACK views. These are separate, and in addition to the
autoTRACK views stored in the buttons above the numeric keypad.
To store an additional Custom View:
1. Adjust zoom, focus, iris, gain, window, subject position, and sensitivity to the desired
positions or settings.
2. Access the Custom Views menu.
3. Enter the number (1-10) of the Custom View to be stored.
4. Press and hold the Recall/Store function command button for 3 seconds. You will
hear one beep.
5. Release the function command button (A confirmation displays *CAMERA DATA
SAVED*).
To recall a Custom autoTRACK View:
1. Verify that the Tracking Ring Package is turned on.
2. Access the Custom Views menu.
3. Using the numeric keypad, select the number of the desired Custom View.
4. Press and release the Recall/Store function command button.
Subject Position Menu
Sensitivity Menu
Custom Views Menu
