CIRCUIT = 12❚
HEATER SETUP
HEATER = ENABLED
RTD SETUP =1 PIPE
Figure 23: Select Circuit Number
At this point, the other options are to move to another CIRCUIT or to the ALL option
through the use of the UP and DOWN arrow keys. In this case, select the green
ENTER key to select this circuit. The flashing cursor now moves to the HEATER
ENABLED line as seen below.
CIRCUIT = 12
HEATER SETUP
HEATER = ENABLED ❚
RTD SETUP =1 PIPE
Figure 24: Heater Setup
Press the ENTER key in order to save the current setting of HEATER ENABLED.
The flashing cursor now moves to the RTD SETUP line. Press the green UP arrow
key and press the green ENTER key to set in the option of 2 PIPE.
