TASCAM CG-2000
29
10 – Specifications
Inputs and outputs
VIDEO INPUTS
Connector type: BNC
Input level: 0.5–2.0 Vp-p
Input impedance: 75 Ω (can turn ON/OFF in menu)
Input format
SD video black burst:
NTSC (RS-170A)
PAL (ITU-R624)
SD video composite sync:
NTSC B/W (RS-170)
HD video tri-level:
720p/50/59.94/60 (SMPTE 296M)
1080p/23.976/24/25/29.97/30/50/59.94/60 (SMPTE
274M)
1080i/23.976/24/25/29.97/30 (SMPTE 274M)
1080PsF/23.976/24/25/29.97/30 (SMPTE RP211)
Permissible frequency deviation: ±10 ppm
WORD/EXT INPUTS
Connector type: BNC
Input level: 0.5–5.0 Vp-p
Input impedance: 75/50 Ω (can set to 75/50/OFF in
menu)
Supported frequencies
WORD CLOCK: 32/44.1/48/88.2/96/176.4/192 kHz
(−4/−0.1/0.0/+0.1/+4% PULL UP/DOWN supported only
when 48/96/192 kHz selected)
ATOM:
10.0 MHz
GPS: 10.0 MHz
Permissible frequency deviation: ±10 ppm
AES3/11 INPUT
Connector type: XLR-3-31 (1: GND, 2: HOT, 3: COLD)
Input level: 0.2–10 Vp-p
Input impedance: 110 Ω
Format: AES11-2003, AES3-2003,
IEC60958-4
Supported frequencies: 32/44.1/48/88.2/96/176.4/192 kHz
(−4/−0.1/0.0/+0.1/+4% PULL UP/DOWN supported only
when 48/96/192 kHz selected)
Permissible frequency deviation: ±10 ppm
CALIBRATION INPUT
Connector type: BNC
Input level: 0.5–5.0 Vp-p
Input impedance: 50 Ω (can turn ON/OFF in menu)
Supported frequencies
ATOM: 10.0 MHz
GPS: 10.0 MHz, PPS
VIDEO OUTPUTS
Connector type: BNC
Output impedance: 75 Ω
Output format
SD video black burst:
NTSC (RS-170A)
PAL (ITU-R624)
SD video composite sync:
NTSC B/W (RS-170)
HD video tri-level:
720p/50/59.94/60 (SMPTE 296M)
1080p/23.976/24/25/29.97/30/50/59.94/60 (SMPTE
274M)
1080i/23.976/24/25/29.97/30 (SMPTE 274M)
1080PsF/23.976/24/25/29.97/30 (SMPTE RP211)
WORD OUTPUTS
Connector type: BNC connector
Output level: 1.0–3.5Vp-p (can set by 0.5V steps
in menu)
Output impedance: 75 Ω
Supported frequencies: 32/44.1/48/88.2/96/176.4/192 kHz
11.2896/12.288 MHz (Super Clock, only connectors 11/12)
(−4/−0.1/0.0/+0.1/+4% PULL UP/DOWN supported only
when 48/96/192 kHz selected)
AES3/11 OUTPUTS
Connector type: XLR-3-32 (1: GND, 2: HOT, 3: COLD)
Output level: 2.5 Vp-p
Output impedance: 110 Ω
Format: AES11-2003, AES3-2003,
IEC60958-4
Supported frequencies: 32/44.1/48/88.2/96/176.4/192 kHz
S/PDIF OUTPUTS
Connector type: RCA pin jack
Output level: 0.5 Vp-p
Output impedance: 75 Ω
Format: IEC60958-3 (S/PDIF)
Supported frequencies: 32/44.1/48/88.2/96/176.4/192 kHz
(−4/−0.1/0.0/+0.1/+4% PULL UP/DOWN supported only
when 48/96/192 kHz selected)
ALARM OUTPUT
Connector type: 6-pin Euroblock connector
Output format: Open collector
Output impedance: 10 Ω
Resistance: 20 V
Maximum current: 50 mA
Performance
Internal oscillator
Type: OCXO (oven-controlled crystal oscillator)
Permitted frequency deviation: ±0.01 ppm (Adjusted value
when shipped new from the
factory)
Frequency temperature characteristics: ±0.05 ppm (0 to 40 ºC)
Long-term frequency stability:
±0.005 ppm (daily)
±0.5 ppm (annually)
