TASCAM CG-2000
13
2 – Names and functions of parts
Basic menu screen operation
Follow these procedures to use the menu screen pages.
To switch items one page at a time:
Press the MENU button repeatedly until the desired menu page
opens.
The pages appear in the following order.
REFERENCE
VIDEO CLOCK
AUDIO CLOCK
TERMINATION
WORD OUT LEVEL
UTILITY 1
UTILITY 2
LOG
To select an item (up and down on screen):
Turn the MULTI JOG dial.
To confirm the selected item:
Press the MULTI JOG dial.
To open a submenu not shown on screen:
Press the MULTI JOG dial.
To move up one level in the menu or return to the
menu:
Press the EXIT/CANCEL button.
To return directly to the Home Screen from menu
mode:
Press the HOME/DISPLAY button.
Menu operation procedures
In this example, we explain how to set the dedicated connector
termination when inputting a calibration signal from a GPS
signal.
1. Press the MENU button to open the
REFERENCE
menu
page.
2. Press the MENU button again to open other pages (three
times to open TERMINATION ).
TERMINATION page open
3. Turn the MULTI JOG dial to select the item (GPS).
GPS selected
4. Press the MULTI JOG dial to open the item’s setting page
(TERMINATION GPS).
GPS page open
5. Turn the MULTI JOG dial to change the setting.
6. Press the MULTI JOG dial to confirm the setting.
7. Repeat steps 5–6 as necessary to set other items.
8. Press the MULTI JOG dial to return to the menu screen. Press
the HOME/DISPLAY button to return to the Home Screen.
NOTE
Press the EXIT/CANCEL button to cancel a menu operation
and return to the menu screen.
