Super Systems SuperDATA User Manual
Page 52
Super Systems Inc
Page 52 of 172
Super Data Operations Manual
Following is a sample ComRbridge.cfg file
--------------------------------------
[Remote Sources]
*RSxx=path to remote inttbl.dat,name
RS01=\\WS1\ssi\comdata,MyWS1
RS01A1=\\WS2\ssi\comdata,MyWS2
RS02=\\WS3\ssi\comdata,MyWS3
[Local Sys Channels]
*SCxx=logical channel,channel name
SC01=101,WS1CH2
SC02=102,SlotMap
*For each system channel a section to define the mapping
[xxx]
*can use either CHAN to map an entire channel or SLxx to define how each
*slot is mapped
KEY: CHAN=remote source, remote chan, IsSysCh (1=Yes, 0=No)
*Note: Can Read/Write to remote system channels Only
*for non-system channels, ComRMap is read only
***OR*** map all slots
*KEY: SLxx=remote source,remote chan,remote slot,slot name,IsSysCh (1=Yes, 0=No)
