MOD_ET2600 note 1.
Note 1. Configured the same as Generic Modbus.
Generic MODBUS Instruments
MOD_PMC note 1
MMI_MOD note 2
Note 1. This protocol uses Modbus FN 03 to read registers and FN 6 or FN 16 to write registers. Values to
be polled are specified in the instrument configuration line.
Note 2. This protocol uses Modbus FN 04 to read registers and FN 6 or FN 16 to write registers. Values to
be polled are specified in the instrument configuration line.
Honeywell Instruments
Generic Honeywell CPL Instrument
CPL_HW note1.
Note 1. The only instrument tested using this protocol is the Honeywell DCP550. . Values to be polled are
specified in the instrument configuration line.
Honeywell Modbus Instruments
HWM_DPR3000 note 1
HWM_GEN note 2
HWM_DPR100 note 2
HWM_DPR180 note 2
HWM_DPR250 note 2
HWM_RSX note 2
HWM_VRX note 2
HWM_VPR note 2
HWM_DR4300 note 2
HWM_DR4500 note 2
HWM_UDC2300 note 2
HWM_UDC3300 note 2
HWM_UDC5300 note 2
Note 1. Supports READ only using Modbus FN 04. Data inputs are read in register pairs, one register for the
mantissa and one for the decimal indicator. Data inputs are converted to integer with implied decimal
location for SuperData. Inputs to be read are selected in the instrument configuration line.
Note 2. Generic Instrument for Honeywell Modbus using Modbus FN 03 For reading data . Data is read as
either Integer single registers or Floating-point as register pairs, each pair representing an IEEE floating
point number. Data inputs are converted to integer with implied decimal location for SuperData. Data to be
read are selected in the instrument configuration line.
Generic MODBUS Instruments
Honeywell instruments may be configured as Generic Modbus instruments. In this case, only integer data is
supported.
MOD_PMC note 1
MMI_MOD note 2
Note 1. This protocol uses Modbus FN 03 to read registers and FN 6 or FN 16 to write registers. Values to
be polled are specified in the instrument configuration line.
Note 2. This protocol uses Modbus FN 04 to read registers and FN 6 or FN 16 to write registers. Values to
be polled are specified in the instrument configuration line.
Yokogawa Instruments
Yokogawa CPL Instruments
CPL_YOK note 1
