Super Systems Inc Page 22 of 172 Super Data Operations Manual
Other Instruments
AllenBradley DF1 Instruments
AB_PLC
AB_SLC
Note 1. The SuperData support for DF1 is a very limited subset of the AllenBradley DF1 protocol.
Note 2: The preferred method for SuperData comms to an AB PLC is via RSLinx (an OPC server) and
SuperData's OPCBridge. This method brings much more flexibility to the overall application.
TypeID Reference
The "Type Name" is used in the Scspsys.cfg file to identify the instrument type. The "Type Number" is displayed in
the SDIO Status View "TYP" column.
Type Name Type Number
(Hex)
CPL_HW (x01)
CPL_YOK (x02)
MOD_PMC (x10)
SSI_CON (x10)
MMI_MOD (x12)
SYS (x14)
BARBER-COLEMAN 560 (x18)
10PRO (x18)
MCARB-V3.0 (x21,x22)
UCARB-V3.0 (x23,x24)
UCARB-V3.5 (x25,x26)
MCARB-IR (x29,x2A)
MCARB-IR-V3.5 (x2B,x2C)
DPSTD-V4.0 (x2E)
DUALPRO-V4.0 (x2F)
CARBPRO-V4.0 (x2F)
MMIGEN-V4.0 (x30)
UNIPRO (x33,x34)
UNIPRO-V3.5 (x35,x36)
CARB-PC (x39)
UNIPRO-V4.0 (x3F)
HWM_GEN (x46)
HWM_DPR3000 (x47)
HWM_DPR100 (x48)
HWM_DPR180 (x49)
HWM_DPR250 (x4A)
HWM_RSX (x4B)
HWM_VRX (x4C)
HWM_VPR (x4D)
HWM_DR4300 (x4E)
HWM_DR4500 (x4F)
HWM_UDC2300 (x50)
HWM_UDC3300 (x51)
HWM_UDC5300 (x52)
MOD_ET2200 (x55)
MOD_ET2400 (x56)
MOD_ET2600 (x57)
MOD_SMPP (x5A)
SSI_CON (x5B)
