Version 1.2.0 Page 36 of 52 SMT398 User Manual
SHBx_USERy(z)
Connector name:
x = A,B,C, or D
User line
divided in 3
groups:
y = 0, 1 or 2
Z = [0:15]
Figure 16: SHB constraints file User pins signals names
Please refer to SHB Header.
Global bus
The global bus is compatible with the TIM standard.
The Global Bus Interface is a memory Interface that follows Texas Instruments’
TMS320C4x External Bus operation standard. Additional information on the standard
is available in the
TMS320C4x User’s Guide chapter 9:
External Bus operation .
When Writing, the FPGA sends data across the global bus to the external device.
When Reading, the external device writes data across the global bus to the FPGA.
